OV1

---

OV1 Credit: USAF

AKA: BORE;NB20.170;PasComSat;Spades;SPP. Status: Operational 1965. First Launch: 1965-01-21. Last Launch: 1971-08-07. Number: 27 . Payload: 36 kg (79 lb). Gross mass: 555 kg (1,223 lb). Height: 1.40 m (4.50 ft).

The OV1, originally called SATAR, was designed to carry a variety of scientific experiments into orbit in a special pod on the Atlas booster when the lift capability of the Atlas was not fully utilized by other experiments thus providing an economical satellite with "bonus" experiments. The OV1 had its own propulsion system which was fired after the satellite was ejected from the booster vehicle.

The OVI remained inside the Atlas-retained structure during the Atlas flight to protect it from aerodynamics loading and heating. The space vehicle coasted for about 8 minutes in space as pre-programmed attitude control maneuvers were performed on command of the propulsion module guidance system to position it for firing of its solid-fuelled motor. OV1 could be launched singly on the side of Atlas or in dual pods on the booster nose. Once in space, it could attain near-circular or highly elliptical earth orbits, high altitude probes or high velocity re-entry missions. Each OV1 could carry a 36 kg payload. Total mass on the Atlas was 1,113 kg for the dual pod load. The satellite was 1.40 m long and 0.68 m in diameter. Contracting agency was the USAF's Office of Aerospace Research. Prime Contractor was Convair Division of General Dynamics Corporation. Associate Contractor was Allegheny Ballistics Laboratory (propulsion system).

Photo Gallery

---

---

OV1-02 Credit: Manufacturer Image

---

---

OV1P Credit: Manufacturer Image

---

---

OV1-07 Credit: Manufacturer Image

---

---

OV1 Credit: Manufacturer Image

---

• OV1-01 - . Payload: ABRES MTV-1. Mass: 85 kg (187 lb). Nation: USA. Agency: USAF. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1965-01-21 . Failure..

• OV1-1 - . Payload: OV1-1. Mass: 555 kg (1,223 lb). Nation: USA. Agency: USAF SAC. Spacecraft: OV1.

• OV1-03 - . Mass: 555 kg (1,223 lb). Nation: USA. Agency: USAF AFSC. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1965-05-28 .

• OV1-02 - . Payload: OV1 Dummy. Mass: 86 kg (189 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. USAF Sat Cat: 1613 . COSPAR: 1965-078A. Apogee: 2,735 km (1,699 mi). Perigee: 408 km (253 mi). Inclination: 144.20 deg. Period: 117.60 min. Radiation data. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-02S - . Mass: 555 kg (1,223 lb). Nation: USA. Agency: USAF AFSC. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. COSPAR: 1965-078xx. Apogee: 2,418 km (1,502 mi). Perigee: 401 km (249 mi). Inclination: 144.20 deg. Period: 114.00 min.

• NB20.170 - . Payload: SPP 29. Mass: 555 kg (1,223 lb). Nation: USA. Agency: USAF AFSC. Spacecraft: OV1. COSPAR: 1965-078xx. Apogee: 2,418 km (1,502 mi). Perigee: 401 km (249 mi). Inclination: 144.20 deg. Period: 114.00 min.

• OV1-04 - . Mass: 88 kg (194 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. USAF Sat Cat: 2121 . COSPAR: 1966-025A. Apogee: 1,008 km (626 mi). Perigee: 884 km (549 mi). Inclination: 144.50 deg. Period: 104.00 min. Thermal control experiments. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-04S - . Mass: 555 kg (1,223 lb). Nation: USA. Agency: USAF AFSC. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. COSPAR: 1966-025xx. Apogee: 1,002 km (622 mi). Perigee: 879 km (546 mi). Inclination: 144.50 deg. Period: 103.80 min.

• OV1-05S - . Payload: BORE. Mass: 114 kg (251 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. USAF Sat Cat: 2122 . COSPAR: 1966-025B. Apogee: 1,056 km (656 mi). Perigee: 985 km (612 mi). Inclination: 144.60 deg. Period: 105.60 min. Optical radiation test. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-07 - . Payload: PasComSat. Mass: 10 kg (22 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1978-01-04 . USAF Sat Cat: 2324 . COSPAR: 1966-063A. Apogee: 1,022 km (635 mi). Perigee: 985 km (612 mi). Inclination: 144.20 deg. Period: 105.20 min. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-08 PasComSat - . Mass: 555 kg (1,223 lb). Nation: USA. Agency: USAF AFSC. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1978-01-04 . USAF Sat Cat: 2324 . COSPAR: 1966-063xx. Apogee: 410 km (250 mi). Perigee: 393 km (244 mi). Inclination: 144.20 deg. Period: 92.60 min.

• OV1-06S - . Mass: 202 kg (445 lb). Nation: USA. Agency: USAF. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1966-12-31 . USAF Sat Cat: 2527 . COSPAR: 1966-099C. Apogee: 290 km (180 mi). Perigee: 287 km (178 mi). Inclination: 32.80 deg. Period: 90.30 min. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-09 - . Mass: 230 kg (500 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. USAF Sat Cat: 2610 . COSPAR: 1966-111A. Apogee: 4,582 km (2,847 mi). Perigee: 475 km (295 mi). Inclination: 99.10 deg. Period: 139.40 min. Radiation bio-hazard experiments. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-10 - . Mass: 130 kg (280 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 2002-11-30 . USAF Sat Cat: 2611 . COSPAR: 1966-111B. Apogee: 604 km (375 mi). Perigee: 541 km (336 mi). Inclination: 93.40 deg. Period: 96.10 min. Radiation data. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-08S - . Mass: 118 kg (260 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1972-02-22 . USAF Sat Cat: 2893 . COSPAR: 1967-072A. Apogee: 557 km (346 mi). Perigee: 529 km (328 mi). Inclination: 101.60 deg. Period: 95.50 min. Carried cosmic ray telescope. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-11 - . Mass: 555 kg (1,223 lb). Nation: USA. Agency: USAF AFSC. Spacecraft: OV1. Decay Date: 1972-02-22 . USAF Sat Cat: 2893 . COSPAR: 1967-072xx. Apogee: 146 km (90 mi). Perigee: 144 km (89 mi). Inclination: 101.70 deg. Period: 87.40 min. OV-1 11 did not reach orbit..

• OV1-12S - . Mass: 140 kg (300 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1980-07-22 . USAF Sat Cat: 2901 . COSPAR: 1967-072D. Apogee: 579 km (359 mi). Perigee: 497 km (308 mi). Inclination: 101.70 deg. Period: 95.40 min. Solar flare observations. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-13 - . Mass: 107 kg (235 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. USAF Sat Cat: 3173 . COSPAR: 1968-026A. Apogee: 9,214 km (5,725 mi). Perigee: 587 km (364 mi). Inclination: 100.00 deg. Period: 198.70 min. Radiation, engineering experiments. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-14 - . Mass: 101 kg (222 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. USAF Sat Cat: 3174 . COSPAR: 1968-026B. Apogee: 9,858 km (6,125 mi). Perigee: 568 km (352 mi). Inclination: 100.00 deg. Period: 207.00 min. Radiation data. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-15S - . Payload: Spades. Mass: 470 kg (1,030 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1968-11-06 . USAF Sat Cat: 3318 . COSPAR: 1968-059A. Apogee: 1,800 km (1,100 mi). Perigee: 153 km (95 mi). Inclination: 89.80 deg. Period: 104.60 min. Studied relationship between atmospheric density and solar radiation. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-16 Cannonball 1 - . Payload: Loads. Mass: 600 kg (1,320 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1968-08-19 . USAF Sat Cat: 3319 . COSPAR: 1968-059B. Apogee: 556 km (345 mi). Perigee: 145 km (90 mi). Inclination: 89.80 deg. Period: 91.50 min. Ionospheric drag tests. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-17S - . Mass: 142 kg (313 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1970-03-05 . USAF Sat Cat: 3823 . COSPAR: 1969-025A. Apogee: 466 km (289 mi). Perigee: 400 km (240 mi). Inclination: 99.10 deg. Period: 93.20 min.

  Atlas 104F was launched from Vandenberg AFB and placed 41 scientific experiments into orbit as part of SAMSO's Space Experiments Support Program (SESP). Solar radiation experiments. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A).

• OV1-19S - . Mass: 124 kg (273 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. USAF Sat Cat: 3825 . COSPAR: 1969-025C. Apogee: 5,551 km (3,449 mi). Perigee: 483 km (300 mi). Inclination: 104.80 deg. Period: 151.10 min. Radiation experiments. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-17A Orbiscal 2 - . Payload: OV1-17P. Mass: 221 kg (487 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1969-03-24 . USAF Sat Cat: 3826 . COSPAR: 1969-025D. Apogee: 309 km (192 mi). Perigee: 175 km (108 mi). Inclination: 99.10 deg. Period: 89.40 min. Radio beacon mountedon OV17 propulsion module. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-18S - . Mass: 125 kg (275 lb). Nation: USA. Agency: USAF OAR. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1972-08-27 . USAF Sat Cat: 3824 . COSPAR: 1969-025B. Apogee: 583 km (362 mi). Perigee: 466 km (289 mi). Inclination: 98.90 deg. Period: 95.20 min. Ionospheric, radiation, electric field data. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .

• OV1-20P - . Mass: 70 kg (154 lb). Nation: USA. Agency: USAF STP. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. Decay Date: 1971-08-28 . USAF Sat Cat: 5394 . COSPAR: 1971-067A. Apogee: 1,932 km (1,200 mi). Perigee: 136 km (84 mi). Inclination: 92.00 deg. Period: 105.90 min.

  Atlas 76F, with two upper stage Orbital Vehicle propulsion modules, OV1-20 and 0V1-21, was launched from Vandenberg as part of SAMSO's Space Test Program (STP). This mission, STP 70-2, successfully placed six spacecraft with nine separate payloads into polar orbits. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A).

• OV1-21P - . Mass: 70 kg (154 lb). Nation: USA. Agency: USAF STP. Class: Earth. Type: Magnetosphere satellite. Spacecraft: OV1. USAF Sat Cat: 5397 . COSPAR: 1971-067B. Apogee: 896 km (556 mi). Perigee: 778 km (483 mi). Inclination: 87.60 deg. Period: 101.70 min. Space craft engaged in investigation of spaceflight techniques and technology (US Cat A). .
