Goddard P-C



Goddard Series P Sec
Rockets of large fuel capacity, with the rocket motor, pumps, and turbines previously developed.
American test vehicle. Section C tests would run through October 10, 1941 and represent the final Goddard rocket flight tests. The series of twenty-four static and flight tests (P13-P36) was made with rockets of large fuel capacity, with the rocket motor, pumps, and turbines previously developed. These rockets averaged nearly 22 ft in length, and were 18 in, in diameter. They weighed empty from 190 to 240 lb. The liquid-oxygen load averaged about 140 lb, the gasoline 112 lb, making "quarter-ton" loaded rockets.

Gross mass: 220 kg (480 lb).
Height: 6.70 m (21.90 ft).
Diameter: 0.46 m (1.50 ft).
Thrust: 3.04 kN (683 lbf).
First Launch: 1940.08.09.
Last Launch: 1941.05.08.
Number: 2 .

More... - Chronology...


Associated Countries
See also
  • Goddard Robert H. Goddard was the father of American rocketry. In a series of rockets flown between World War I and World War II, he solved all of the fundamental problems of guided liquid propellant rockets. More...

Associated Manufacturers and Agencies

Goddard P-C Chronology


1939 November 18 - . LV Family: Goddard. Launch Vehicle: Goddard P-C.
  • Goddard Series P Section C rocket tests - . Nation: USA. Related Persons: Goddard. Section C tests would run through October 10, 1941. The series of twenty-four static and flight tests (P13-P36) was made with rockets of large fuel capacity, with the rocket motor, pumps, and turbines previously developed. These rockets averaged nearly 22 ft in length, and were 18 in, in diameter. They weighed empty from 190 to 240 lb. The liquid-oxygen load averaged about 140 lb, the gasoline 112 lb, making 'quarter-ton' loaded rockets.

1939 December 2 - . LV Family: Goddard. Launch Vehicle: Goddard P-C.
  • Goddard Series P Section C rocket static test - . Nation: USA. Related Persons: Goddard. Summary: Static test at flight tower; steady 40-sec run; lift 760 lb. .

1940 May 15 - . LV Family: Goddard. Launch Vehicle: Goddard P-C.
  • Goddard Series P Section C rocket static test - . Nation: USA. Related Persons: Goddard. Summary: Static test, flame hot, apparently large lift; ground behind dame deflector looked melted..

1940 June 11 - . LV Family: Goddard. Launch Vehicle: Goddard P-C.
  • Goddard Series P Section C rocket static test - . Nation: USA. Related Persons: Goddard. Summary: Static test, steadier run 43.5 sec, longest to date; red-hot stones seen to fly up out of cement gas deflector..

1940 August 9 - . LV Family: Goddard. Launch Vehicle: Goddard P-C.
  • Goddard Series P Section C rocket flight test - . Nation: USA. Related Persons: Goddard. Apogee: 0.0900 km (0.0559 mi). Summary: First flight with pumps, altitude 300 ft; velocity low, 10-15 mph. .

1941 January 6 - . LV Family: Goddard. Launch Vehicle: Goddard P-C.
  • Goddard Series P Section C rocket static test - . Nation: USA. Related Persons: Goddard. Summary: Static test, highest lift so far recorded, 985 lb. .

1941 May 8 - . LV Family: Goddard. Launch Vehicle: Goddard P-C.
  • Goddard Series P Section C rocket flight test - . Nation: USA. Related Persons: Goddard. Apogee: 0.0800 km (0.0497 mi). Summary: Second flight with pumps, altitude 250 ft; then heeled away from tower..

1941 July 17 - . LV Family: Goddard. Launch Vehicle: Goddard P-C.
  • Goddard Series P Section C rocket static test - . Nation: USA. Related Persons: Goddard. Summary: Static test: duration 34 sec; average thrust 825+ lb; gas ejection velocity 4060 ft/sec; average thrust per pound of fuel per second 128; mechanical horsepower 3040; liquid oxygen 131.7 lb; gasoline 91.5 lb; ratio oxygen to gasoline 1.43. .

1941 October 19 - . LV Family: Goddard. Launch Vehicle: Goddard P-C.
  • End of Goddard sounding rocket tests - . Nation: USA. Related Persons: Goddard. The Goddard P series pump-turbine tests had run from November 1939-October 1941. The series included 15 proving-stand tests and nine attempts at flight tests, of which only two resulted in flights. Average interval between tests was 28 days. This also ended Goddard development of liquid fuel rockets for space flight. Beginning in September 1941 with the impending involvement of the US in the world war, the Goddard rocket establishment worked under contracts with the Bureau of Aeronautics of the Navy Department and the Army Air Forces. Up to that point Goddard's team had completed 103 liquid rocket proving stand tests and made 48 attempts at flight tests, of which 31 resulted in rocket flights
